• Advanced LiFePO₄ Technology
A superior alternative to lead-acid batteries, offering enhanced safety, thermal stability, and reliable performance for high-demand applications.
• Long Life & Consistent Performance
Delivers 3000+ charge cycles with minimal capacity loss, ensuring long-term reliability and reduced replacement costs.
• Fast Charging & High Efficiency
Supports high-current charging, reaching up to 100% in 1–2 hours with excellent energy efficiency and quick backup readiness.
• Smart BMS Protection
Inbuilt advanced BMS safeguards against overcharge, deep discharge, short circuit, and temperature variations for safe operation.
• Maintenance-Free & Eco-Friendly Design
Lightweight, compact, non-toxic (100% cobalt-free), low self-discharge (<3%/month), fully recyclable, and requires zero maintenance.
| Model | LFP7360 |
|---|---|
| Battery Type | Lithium Iron Phosphate (LiFePO₄) |
| Nominal Voltage | 73.6V |
| Capacity | 60Ah |
| Energy | ~4416 Wh |
| Cycle Life | 3000+ Cycles |
| Charging Voltage | 82.8V – 83.2V |
| Operating Temperature | 0°C – 45°C (Charge) / -20°C – 60°C (Discharge) |
| Charge Current | 30 A (Recommended) |
| Max Charge Current | 60 A |
| Discharge Current | 40 A (Recommended) |
| Short Circuit Current | ~120 A |
| BMS Protection | Inbuilt Protection System |
| Communication | Optional (CAN / RS485 / RS232) |
| Display | Optional (LED / LCD Indicator) |
| Dimensions (WxDxH mm) | ~600 × 450 × 180 mm |
| Weight (kg) | Approx. 32–42 kg |
| Installation | Floor / Rack Mount |
| Max Operating Altitude | ≤2000 m |
| IP Rating | IP20 |
| Design Life | Up to 10 Years |
